Features
- Autonomous operation
- Automatic spot finder
- Direct analog output
- -4 to 1652°F temperature range
- 80 x 80px optical resolution
- 50Hz frame rate
- 7.5 to 13µm spectral range
- 190:1 optical resolution (12° optics)
- 80° lens covers a wide area
- 100mK thermal sensitivity
- ±2°C or ±2% accuracy
- Manual motor focus
- USB, PoE, 5-30VDC power supply
The Optris Xi80 infrared camera is an autonomous stand alone solution to temperature monitoring. It features an automatic spot finder to easily locate hot and cold spots without manual positioning. It has a temperature range of -4 to 1652°F with a range of available optics and 80 x 80 resolution. The Xi80 ultizises a 2.0 USB, ethernet, PoE, and RS485 interface with direct 0/4 to 20mA analog output. Up to 3 industrial PIFs can be stacked with up to 9 analog or alarm outputs.
Complimentary PIX Connect software offers both on and offline data analysis for the Optris Xi80. It allows automatic and remote control of the camera, with the ability to display multiple camera images in different windows. A video recording and snapshot function allows complete analysis and documentation of video sequences with detailed frames. The PIX Connect software features many different language options including a translation tool, and can display temperature in °C or °F. It is compatible with Windows Vista, 7, 8, and 10.
