Features
- -4 to 212°F (-20 to 100°C) temperature range
- ±2°C accuracy
- 382 x 288px optical resolution
- 80Hz frame rate can switch to 27Hz
- 8 to 14µm spectral range
- 390:1 optical resolution (18° optics)
- 80mK thermal sensitivity
- Analog or digital outputs
- USB power supply
- Aids in identifying infected passengers in a crowd
- Easy installation and operation of the inspection system
- Alarm signal when skin temperature reaches predefined alarm value
- Snapshot function of IR image
- Extensive software included, runs on a standard PC
The Optris Xi400 T010 is an infrared camera optimized for fever screening. Viral epidemics like the current coronavirus / COVID-19 have created a worldwide demand for infrared cameras able to screen for a fever condition in humans. The Xi400 T010 provides fast, non-contact screening that can detect individuals with high body temperatures that may indicate a fever.
The Optris Xi400 T010 has a calibrated range of -4 to 212°F (-20 to 100°C) and is accurate to ±2°C. The temperature resolution of 0.1 °C detects the smallest of temperature variances. The system works discreetly. The software singles out the people whose skin temperature exceeds the predefined value. The visual alarm gives users the possibility to identify and isolate individuals so that a medical examination can be done discreetly. If necessary, the software offers the possibility to take automatically IR image snapshots when a person trips the alarm. The installation of the whole system including the infrared camera and its extensive software package is simple and the system can be set up or relocated quickly. The system is password-protected to prevent unauthorized changes.
