Description / توضیحات
Features
Silicon strain gauge sensors successfully field proven in many thousands of installations.
Simple, elegant sensor packaging with very few parts; achieves exceptionally high reliability.
Aluminum housing has durable, corrosion resistant epoxy finish; 316 ss housing also available; both meet the ratings of NEMA 4X and IEC IP66.
Remote configuration or locally via the optional LCD Indicator.
Can be provided with numerous configurations of direct connect or remote mount seals.
HART protocol allows multidrop topology.
SIL2-Certified transmitter offered as an option.
CE marked; complies with applicable EMC, ATEX, and PED European Union Directives.
The IAP10 and IGP10 are offered with integral process connections for sanitary, and pulp and paper installations. Also, the IGP10 is offered for high gauge pressure applications to 52, 105, or 210 MPa (7500, 15,000, or 30,000 psi).
Sensor wetted parts materials include Co-Ni-Cr, 316L ss, and nickel alloy¹; additionally, Monel, tantalum, and gold-plated 316L ss sensors are offered for the IAP20/IGP20.
Multi-marking available for ATEX, CSA, and FM intrinsically safe applications. User determines and permanently marks the certification to be applied.
Complies with NAMUR NE 21 interference immunity requirement, and NAMUR NE 43 analog output overrange and underrange annunciations.
