IDP10-T22A25D-M1L1 | Foxboro IDP10 Pressure Transmitter

Name: IDP10-T22A25D-M1L1 | Foxboro IDP10 Pressure Transmitter
Brand: Foxboro
Price: 1785300000 IRR
Availability: InStock

برند :

Foxboro

پارت نامبر :

IDP10-T22A25D-M1L1

شماره انبار :

ST-43762

زمان تحویل:

12 هفته

قیمت حدودی:

178,530,000 تومان

به دلیل سفارشی بودن کالاها و نوسانات قیمت ارز، قیمت‌ها حدودی بوده. لطفا برای اطلاع از قیمت بروز کالا استعلام بگیرید.

تامین کننده

یاران صنعت فجر

ارسال به سراسر کشور

ضمانت اصالت و سلامت فیزیکی کالا

در مورد این محصول

ویژگی ها / Specifications

kPa	0.12 and 7.5
mbar	1.2 and 75
Model	IDP10 - I/A Series, Electronic d/p Cell Transmitter for Differential Pressure Measurement
inH2O	0.5 and 30
Covers	316 ss
Sensor	316L ss
Fill Fluid	Silicone
Product Number	IDP10-T22A25D-M1L1
Electrical Safety	D - ATEX II 2 GD. EEx d IIC, Zone 1³
Optional Selections	-M1
Mounting Bracket Set4	Standard Style Painted Steel Bracket with Plated Steel Bolts (not available with LP1 structure)
Electronics Versions and Output Signal	-T - Intelligent; Digital, HART and 4 to 20 mA (Version -T)
Transmitter with Traditional Structure	22
Conduit Connection and Housing Material	5 - M20 Conduit Connection, Both Sides, Aluminium Housing (With Electrical Safety Codes E, D, M, and N only)
Span Limits (Differential Pressure Units)	A¹
Process Connector Type (Material Same as Process Cover Material)²	2 - 1/2 NPT, Not with Structure Codes 78 or 79, or pressure seals

Description / توضیحات

Ordering Information -L1 - Digital Indicator, Pushbuttons, and Window Cover NOTE: Span Limit Code A is not available with pressure seals, expect for Sanitary Spud Seals Models PSSSR-.4 and PSSST-.4. Select Code "0" if a pressure seal is specified. Otherwise select Code 1 through 7. Cover lock provided as standard with Electrical Safety Codes D, B, G, and M. Mounting sets not offered with direct connect (flange mount) seals.
