Ordering Information
Well Type Well Connection Well Material Available with Sensor Length Codes
Plain 3/4 NPT External 316 ss A, D, G, J, L, P, and R
With ATEX and FM intrinsically safe versions of the transmitter, and with ATEX, CSA, FM, and IECEx explosionproof/flameproof versions of the transmitter.
Input configuration can be changed in the field by changing wiring terminations and reconfiguring.
Quantity of one Foxboro sensor that is listed under Measurement Input Type. Length is Dimension U or U + T as shown in the Dimensions-Nominal section of PSS 2A-1F5 A and in DP 020-462, where U is the insertion length, and T is the lagging length of 76 mm (3 in). See Note (d) below.
Transmitter is configured for measurement type specified, whether sensor is included or not. User can change configuration to a different type using the appropriate configurator for selected protocol.
Flameproof and explosionproof approvals and certifications not available with Thermowell Code NA (user-supplied thermowell).
For HART version 7 (-H), contact Global Customer Support for availability of CSA and FM certification.
With Option -L1, CSA is explosionproof only.
