Features
- Display range: -1999 to 9999
- 7-segment LCD display with 9mm character height
- Various output options (Default : Indicator) RS485 communication output, current (4-20 mA DC), NPN/PNP open collector output, relay contact output
- Max. measuring inputs: 50 VDC, 250 VAC, 500 mA DC, 5A AC
- High/Low scale function for high performance
- AC frequency measurement : Range 0.1 to 9999Hz
- Functions:
- Monitoring function for max. and min.
- Display value function
- Display cycle delay function
- Zero function
- High display correction function
- Current output scale function
- Power supply : 12-24VDC/VAC, 100-240VAC
The Autonics MT4N series panel meter is a small-sized instrument with various functions such as AC frequency measuring function, zero adjustment function
and transmission output scale function. The MT4N series realizes high resolution of 1/12,000 and color changeable LCD display to increase visibility; in
addition, its compact size makes space saving installation possible. Also, wide display range from 1999 to 9999 and various output options are essential
characteristics of MT4N series.
