| Bracket | 3Bracket Type Angle Bracket Material 316 SS Customer Tag 1 = One Wired Stainless Steel Tag (Up to 4 lines 26 char/line) Unassembled |
| Adapters | A6 = 1/2 NPT 316 SS Certified Conduit Plug Certifications & |
| Protocol | HAnalog Output 4-20mA dc Digital Protocol HART Protocol Customer |
| Software | 1 = Standard DiagnosticsOutput Limit, |
| Warranty | F1 = Calibration Test Report & Certificate of Conformance (F3399) Certifications & Warranty FE = FMEDA (SIL 2/3) Certification (FC33337) |
| Materials | 0 = None Vent/Drain Type/Location 0 Head Type NoneVent Type None Location None Vent Material None Gasket Materials 0 = None Head/Connect Orientation 1 Meter Body & Connection Orientation Standard, High Side Left, Low Side Right / Std Head OrientationApprovals A = <FM> Explosion proof, Intrinsically Safe, Non-incendive, & DustproofElectronic |
| Connection | GSize/Type 1/2" NPT (female)Material Same as Process Head Bolt/Nuts |
| Selections | BIndicator Basic Ext Zero, Span & Config Buttons None Languages EN Application |
| Calibration | AAccuracy Standard Calibrated Range Factory Standard Calibration Qty Single Calibration Mounting |
| URL/Max Span | 50 (3.5) LRL -14.7 (-1.0) |
| Configuration | S = Factory Standard Accuracy and |
| Connection Type | CMaterial Polyester Powder Coated Aluminum Connection 1/2 NPT Lightning Protection None Output/ |
| Protect Settings | 3 Write Protect Enabled Fail Mode High> 21.0mAdc High & Low Output Limits Honeywell Std (3.8 - 20.8 mAdc)General |
| 316 Stainless Steel Barrier Diaphragm Material | 316L SSFill Fluid 1 = Silicone Oil 200Process |
