ویژگی ها / Specifications
| Model | Programmable Automation Controller |
| Roaming | Supported within an SSID (Service Set Identifier) only |
| -W models | DFARS |
| Topologies | Infrastructure, Ad-Hoc |
| Transmit Power | 15 dBm maximum |
| Memory Total RAM | 32 MB |
| RAM File Storage | 2.5 MB |
| Antenna Connector | Reverse polarity SMA (RP-SMA or RSMA) |
| Frequency 802.11a | 5.180–5.240 GHz, 5.745–5.825 GHz |
| Battery-backed RAM | 8 MB |
| Flash File Storage | 4 MB |
| Frequency 802.11b/g | 2.412–2.472 GHz, 2.484 GHz |
| All models except -W models | CE, RoHS, DFARS |
| Total RAM for PAC Control Strategies | 16 MB |
| (Models with manufacture dates of November 2008 through May 2014 with firmware R8.4 or higher) McroSD card slot | supports microSD cards up to 2 GB. |
| Removable storage (Models with manufacture dates of June 2014 and newer. Requires firmware R9.4a or higher and loader R6.1a or higher) MicroSD card slot | supports microSD or microSDHC cards to 32 GB. |
| Serial Communication Four serial ports that can be used as general purpose ports or for serial I/O units; each port is software configurable as either RS-232 (Tx, Rx, COM, DTR, DCD, RTS, CTS) or as RS-485 (2-wire, 4-wire, optional termination, optional biasing); optional mistic signal interrupts. Buffer size | 512 bytes each for RX and TX. |
Description / توضیحات
Specifications
Processor 266 MHz 32-bit ColdFire® 5475 with integrated floating-point unit (FPU)
Backup battery SNAP-PAC-S1s with serial number 625654 or higher and all SNAP-PAC-S2s: Rechargeable (recharges whenever the brain has power), 1-year power-off data retention (replacement part number: SNAP-PAC-BATTERY-ML2430)
SNAP-PAC-S1s with serial number 625653 or lower: User-replaceable 3.6-volt TL 5242 /W lithium, 10-year minimum power-off data retention (replacement part number: G4BATT32)
Ethernet Communication (wired) to host and I/O Two independent 10/100 Mbps Ethernet network interfaces (RJ-45 connectors). Each interface has a separate IP address (separate subnet).
Ethernet Communication (wireless)* Wireless LAN interface with separate IP address.
Security: 802.11i; AES - Compatible with WPA2 Personal, TKIP - Compatible with WPA Personal, WEP. Note: TKIP/AES security is not supported in Ad-Hoc mode.
Power requirements 8–32 VDC ±0.5, 11.3 VA maximum
(SNAP-PAC-S1 controllers with serial numbers below 500,000 use 8–24 VDC)
Operating temperature
Storage temperature
Humidity -20 °C to 60 °C
-40 °C to 85 °C
0% to 95% relative humidity, non-condensing
Software
PAC Project Basic
PAC Project Professional
REST API Includes programming, HMI software, and configuration software; included with purchase of controller.
PAC Project Basic plus OPC 2.0-compliant OPC server, OptoControl strategy and OptoDisplay project importing, support for serial mistic I/O units, and Ethernet link redundancy support.
Use HTTPS to access data (read/write or read-only) from controller tags using your chosen programming language. Data returned in JSON. More information at developer.opto22.com
Number of charts that can run simultaneously 32
Other features Multiple protocol support including TCP/IP, FTP, SNMP v2.0c (with firmware 8.2a), Modbus/TCP, EtherNet/IP™, and OptoMMP™.
Real-time clock
FTP server/client with file system (in RAM and in removable storage)
Ethernet link redundancy or network segmenting
Agency certifications (-W models only) U.S., FCC Part 15 Subpart C; Canada, IC RSS-210
(-FM models only) Factory Mutual approved
* Requires a Wired+Wireless model (SNAP-PAC-S1-W or SNAP-PAC-S2-W)
