Features
- Swivel mounted
- Thrust type
- Control signal options:
- 0 to 20 psig
- 3 to 15 psig
- 3 to 27 psig
- Accuracy: ±1% of full scale
- Stall Thrust: 1200 lbs (545 kg)
- Maximum Friction Load: 300 lbs (136 kg)
- Minimum Weight Load: 400 lbs (136 kg)
- Temp limits: 0 to 170°F (-17, 8 to 77°C)
- Full stroke time: 2 sec or less
The Rosemount Analytical 4x5 Thrust Type Power Positioners are swivel mounted damper drives control signals up to 27 psig. The 4x5 Thrust Type Power Positioner features a dust cover, internal heater, power air supply and internal air locking system. The 4x5 has a fast response to small input signal charges due to high internal gain. Maintenance is simple with the frame construction design.
Applications for the 4x5 Thrust Type Power Positioners include:
Steel mills
Refineries
Petrochemical
