Description / توضیحات
The VEGAPULS 64 is a sensor for continuous level measurement of liquids. With small tanks or in case of narrow space the small process fittings offer special advantages. The very good signal focusing enables the use in vessels with many installations such as e.g. stirrers and heating spirals.
Benefits
Exact measuring results independent of process conditions
High plant availability, because wear and maintenance-free
Maintenance-free operation through non-contact measuring principle
Technical Specifications
Measuring range - Distance 30 m [Meter - Foot]
Process temperature -196 ... 200 °C [°C - °F]
Process pressure -1 ... 25 bar [Bar - kPa - psi]
Accuracy ± 1 mm
Frequency 80 GHz
Beam angle = 3°
Version With plastic horn antenna ø 80 mm
Thread with integrated horn antenna
Flange with encapsulated antenna system
Hygienic fitting with encapsulated antenna system
Materials, wetted parts PFA
PTFE
316L
Alloy C22 (2.4602)
PEEK
Threaded connection = G¾, = ¾ NPT
Flange connection = DN50, = 2"
Hygenic fittings Clamp = 2", DN50 - DIN32676, ISO2852
Slotted nut = 2", DN50 - DIN 11851
DRD connection ø 65 mm
for NEUMO BioControl D50 PN16 / 316L
Seal material EPDM
FKM
FFKM
Housing material Plastic
Aluminium
Stainless steel (precision casting)
Stainless steel (electropolished)
Protection rating IP66/IP68 (0,2 bar)
IP66/IP67
IP66/IP68 (1 bar)
Output 4 … 20 mA/HART - two-wire
Ambient temperature -40 ... 80 °C
