خانه/ برق و الکترونیک/ سنسور/ Rosemount/ 0065L24D0035Y0435F40I1Q8R01R22R03R04XAV10 | Rosemount | Pt 100 RTD (IEC 751) with Barstock Thermowell
3218
سنسور

0065L24D0035Y0435F40I1Q8R01R22R03R04XAV10 | Rosemount | Pt 100 RTD (IEC 751) with Barstock Thermowell

برند :

Rosemount

پارت نامبر :

0065L24D0035Y0435F40I1Q8R01R22R03R04XAV10

شماره انبار :

ST-3154

زمان تحویل:

12 هفته

قیمت حدودی:

117,290,000 تومان

به دلیل سفارشی بودن کالاها و نوسانات قیمت ارز، قیمت‌ها حدودی بوده. لطفا برای اطلاع از قیمت بروز کالا استعلام بگیرید.

تامین کننده

یاران صنعت فجر

یاران صنعت فجر

ارسال به سراسر کشور

ضمانت اصالت و سلامت فیزیکی کالا

ویژگی ها / Specifications

Dye testR03 = Thermowell dye penetration testing
ExtensionD = DIN standard 12 1.5, M24 1.5 Head connection, 1/2-in. NPT Instrument connection, 300 SST Materials\
Sensor type4 = RTD, dual element, 3-wire, –196 to 300 °C (–321 to 572 °F) Temperature range
Product typePt 100 RTD (IEC 751) with Barstock Thermowell
Connection headL = TZ–A/BL (BUZH) aluminum w/ cable gland, 65 IP rating, M20 1.5 Conduit/cable entry
Shipping weight6 Kg
Special cleaningR04 = Thermowell special cleaning
Assemble to optionsXA = Assemble sensor to specific temperature transmitter (PTFE paste)
Thermowell materialY = 1.4571 (316Ti SST)
Immersion length (U)0435 = Non-standard immersion length (available from 50 to 1000 mm in 5 mm increments)
External pressure testR01 = Thermowell external pressure testing
Internal pressure testR22 = Internal pressure test
Material certificationQ8 = Thermowell material certification, DIN EN 10204 3.1
Product certificationsI1 = ATEX Intrinsic Safety Approval
Sensor lead wire termination2 = Terminal block (DIN 43762)
Extension length (N) in millimeters0035 = 35 mm
Sensor calibration with works certificate (available with 65 only)V10 = Sensor calibration with works certificate (available with 65 only)

Attachment / فایل ضمیمه

Temperature Sensors and Thermowells
