Model and Suffix Codes
Material Certificate: Mill sheets: /M01 - 1. Meterbody
Refer to Table 1.
Users must consider the characteristics of selected wetted parts material and the influence of process fluids. The use of inappropriate materials can result in the leakage of corrosive process fluids and cause injury to personal and/or damage to plant facilities. It also possible that the instrument itself can be damaged and that fragments from the instrument can contaminate the user's process fluids.
Be very careful with highly corrosive process fluids such as hydrochloric acid, sulfuric acid, hydrogen sulfide, sodium hypochlorite, and high temperature steam (+150?C [+302?F] or above).
In case of B (ASTM CF8M), the process connection is available for ANSI (AAx, BAx, BSx, CAx) and DIN (ADx, BDx)
Refer to Table 2.
In case of an explosion type,it depends for an electrical connection on the kind of an explosion protect type. Refer to "OPTION SPECIFICATIONS (FOR EXPLOSION PROTECTED TYPE)"
In case of /FF1 or /CF1, CF11, /KF2, /KS2, /SF2, /SS2 the screw length is deeper than ANSI standard for 0.5 to 2 threads.
Indicator is not available for remote type detector.
