6900GM12 | CCS 6900G Series Pressure Switch

Name: 6900GM12 | CCS 6900G Series Pressure Switch
Brand: CCS
Price: 1108500000 IRR
Availability: InStock

برند :

CCS

پارت نامبر :

6900GM12

شماره انبار :

ST-37279

زمان تحویل:

16 هفته

قیمت حدودی:

110,850,000 تومان

به دلیل سفارشی بودن کالاها و نوسانات قیمت ارز، قیمت‌ها حدودی بوده. لطفا برای اطلاع از قیمت بروز کالا استعلام بگیرید.

تامین کننده

یاران صنعت فجر

ارسال به سراسر کشور

ضمانت اصالت و سلامت فیزیکی کالا

در مورد این محصول

ویژگی ها / Specifications

Model	6900G Series Pressure Switch
Relay	SPDT or DPDT
O-Ring	Buna N
Deadband	Approximately 2 to 220 psi, 13.79 to 1516.8 kPa, 0.14 to 15.2 bar
Condition	New & Original in Factory Packing
Diaphragm	Polyimide
Decreasing	1 to 3180 psig, 6.9 to 21,925.3 kPa, 0.07 to 219 bar
Increasing	3 to 3400 psig, 20.7 to 23,442.2 kPa, 0.21 to 234 bar
Pressure Port	1/4"-18 Female NPT Aluminum
Proof Pressure	7500 psig, 51,710.7 kPa, 517 bar
Factory Warranty	12 Months
System Pressure (Maximum)	5000 psig, 34,473.8 kPa, 345 bar

Description / توضیحات

The general purpose 6900G Series is the most popular, all-around, all-aluminum gage pressure switch. It is designed with high vibration and shock resistance utilizing Dual Snap® disc spring technology ensuring high accuracy and repeatability. It comes with high over-pressure capabilities and still relatively compact in size to conveniently mount on panels. NEMA 4X and IP66 rating is optimum for wet conditions. It meets the demand for all applications commercial, industrial and otherwise. Adjustable Set Point Range: Wetted Materials: CSA, CRN, CE Mark, General Purpose
